MI WI-FI Range Extender AX1500 EU

Description

• Dimensions: 84 × 82 × 168 mm

• Product Colour: White

• Hardware Configuration:

  • 2.4GHz Wi-Fi: 2×2 (supports up to IEEE 802.11n protocol with a theoretical max rate of 300 Mbps)

  • 5GHz Wi-Fi: 2×2 (supports up to IEEE 802.11ax protocol with a theoretical max rate of 1201 Mbps)

  • Antenna: 2 high-gain antennas

  • Heat Dissipation: Natural heat dissipation

  • Network Port: 1 × 10/100/1000 Mbps LAN port

  • LED Indicator: System indicator, Signal indicator

  • System Reset Button: ×1

  • WPS/Mesh Networking Button: ×1

• Protocol Standard: IEEE 802.11 a/b/g/n/ac/ax, IEEE 802.3/3u/3ab

• Wireless Specifications:

  • Dual-band: 2.4GHz, 5GHz

  • Modulation:

    • 11b: DSSS — DBPSK (1 Mbps), DQPSK (2 Mbps), CCK (5.5/11 Mbps)

    • 11a/g: OFDM — BPSK (6/9 Mbps), QPSK (12/18 Mbps), 16QAM (24/36 Mbps), 64QAM (48/54 Mbps)

    • 11n: MIMO-OFDM — BPSK, QPSK, 16QAM, 64QAM; Data rate: MCS0–MCS15

    • 11ac: MIMO-OFDM — BPSK, QPSK, 16QAM, 64QAM, 256QAM

    • 11ax: MIMO-OFDMA — BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
